VB-2000 Series Oil-Free Piston Vacuum Pumps
For multi-station automation, vacuum holding or packaging equipment, provide the gas composition, operating schedule, pipework layout, ambient conditions and available cooling space. Confirm connection dimensions, motor protection, inlet filtration, exhaust arrangements, service intervals and included accessories. For hospital or other medical suction systems, define equipment standards, air-quality requirements and system validation with the integrator. Continuous-duty capability and noise levels require confirmation for the proposed installation.
Image Gallery
VB Series Technical Specifications (Featuring VB-2000 Specifications)
| Model | Voltage | Freq. | Power | Current | Max Vacuum | Max Flow | Port Size | Noise | Weight |
|---|---|---|---|---|---|---|---|---|---|
| VB-2000V High Airflow | 110V | 60 Hz | 0.60 kW | 5.3 A | -700 mmHg (-93.3 kPa) | 208 L/min | 3/8" NPT/G | 60 dB(A) | 11.0 kg |
| 220V | 50 Hz | 0.55 kW | 2.5 A | 170 L/min | |||||
| VB-2000H High Vacuum | 110V | 60 Hz | 0.60 kW | 5.2 A | -740 mmHg (-98.6 kPa) | 155 L/min | |||
| 220V | 50 Hz | 0.55 kW | 5.3 A | 128 L/min | |||||
| VB-400V | 110V | 50 Hz | 0.24 kW | 2.7 A | -680 mmHg | 50 L/min | 1/4" NPT/G | 56 dB(A) | 6.5 kg |
| 110V | 60 Hz | 0.25 kW | 2.3 A | 60 L/min | |||||
| 220V | 50 Hz | 0.22 kW | 1.1 A | 50 L/min | 7.8 kg | ||||
| 220V | 60 Hz | 0.21 kW | 1.0 A | 60 L/min | |||||
| VB-900V / H | 110V | 60 Hz (V) | 0.19 kW | 1.8 A | -685 mmHg | 95 L/min | 7.85 kg | ||
| 220V | 50 Hz (V) | 0.17 kW | 0.8 A | -685 mmHg | 85 L/min | ||||
| 110V | 60 Hz (H) | 0.23 kW | 2.3 A | -740 mmHg | 68 L/min | ||||
| 220V | 50 Hz (H) | 0.16 kW | 0.7 A | -740 mmHg | 60 L/min | ||||
| VB-1200V / H | 110V | 60 Hz (V) | 0.45 kW | 4.1 A | -700 mmHg | 125 L/min | |||
| 220V | 50 Hz (V) | 0.24 kW | 1.5 A | -700 mmHg | 105 L/min | ||||
| 110V | 60 Hz (H) | 0.30 kW | 2.9 A | -740 mmHg | 95 L/min | ||||
| 220V | 50 Hz (H) | 0.35 kW | 1.5 A | -740 mmHg | 85 L/min | ||||
| VB-1400V / H | 110V | 60 Hz (V) | 0.67 kW | 5.9 A | -700 mmHg | 145 L/min | |||
| 220V | 50 Hz (V) | 0.45 kW | 1.7 A | 120 L/min | |||||
| 110V | 60 Hz (H) | 0.44 kW | 3.9 A | -740 mmHg | 105 L/min | ||||
| 220V | 50 Hz (H) | 0.40 kW | 1.6 A | -740 mmHg | 95 L/min | ||||
| VB-1800V / H | 110V | 60 Hz (V) | 0.59 kW | 5.1 A | -700 mmHg | 185 L/min | 3/8" NPT/G | 60 dB(A) | 11.0 kg |
| 220V | 50 Hz (V) | 0.55 kW | 2.5 A | -700 mmHg | 155 L/min | ||||
| 110V | 60 Hz (H) | 0.58 kW | 5.2 A | -740 mmHg | 135 L/min | ||||
| 220V | 50 Hz (H) | 0.55 kW | 2.5 A | -740 mmHg | 110 L/min |
Key Advantages of the VB-2000 Flagship Vacuum Pump
Performance Curve & System Sizing
Compare VB-2000V and VB-2000H under the stated voltage, frequency and measurement conditions. Confirm flow at your working vacuum using the performance curve. Review vessel volume, leakage and simultaneous gas loads when estimating evacuation time or holding performance.
Connections & Pressure-Loss Review
Confirm the port dimensions, thread standard and adapters for the quoted configuration. Review pipe diameter, length, fittings and exhaust arrangements against the required flow. Assess pressure losses for the complete system rather than assuming a port size prevents throttling.
Cooling & Operating Schedule
Confirm cooling clearance, enclosure ventilation, ambient limits and the motor duty rating for the selected configuration. Review thermal protector trip and reset behaviour and machine controls against the proposed load and operating schedule.
Oil-Free Operation & Installation Review
Oil-free operation alone does not establish contamination-free performance or remove maintenance requirements. Confirm inlet filtration, exhaust arrangements and service intervals. Review vibration mounting and verify noise measurement distance, load and installation conditions.
Target Industrial & Automation Applications
🪵 Multi-Head CNC Routers & Edge-Banders
For CNC beds or edge-banding equipment, define workpiece leakage, holding force, active zones and cycle time. Confirm flow at the working vacuum and review filtration, pressure control and duty cycle for the complete machine.
📦 High-Volume Thermoforming & Blister Packaging
For thermoforming or blister packaging, define process pressure, vessel volume, evacuation time and operating schedule. Review materials, filtration, exhaust arrangements and any food or pharmaceutical validation requirements with the equipment integrator.
🏥 Central Hospital & Dental Vacuum Networks
For hospital or dental suction networks, assess required pressure, total flow, filtration, collection and equipment validation with the integrator. Review system capacity, redundancy and protective controls before selecting a configuration for primary or backup duty.
🔬 Pilot-Scale Vacuum Drying & Evaporation
For multiple evaporators, desiccators or filtration branches, provide combined gas load, branch pressures and simultaneous-use requirements. Confirm gas compatibility, condensation protection, controls and exhaust treatment for the proposed installation.
Technical & Application FAQ
What makes the VB-2000 the flagship model of the VB dry piston pump series?
Review the VB-2000 model-specific airflow, motor and connection data at the required voltage and frequency. Compare available flow at the working vacuum with other configurations. Size multi-station equipment or reservoirs using total gas load, vessel volume, leakage and evacuation requirements.
How does the performance of VB-2000H differ from VB-2000V under deep vacuum conditions?
Compare VB-2000V and VB-2000H using performance curves under the same electrical and measurement conditions. Confirm flow at your required working vacuum. Listed maximum airflow and limiting vacuum are separate selection values unless the curve establishes the operating point.
Why is the 3/8-inch port size essential for the VB-2000's high displacement performance?
Confirm the port dimensions, thread standard and adapters for the quoted configuration. Review connected pipe diameter, length, fittings and simultaneous flow requirements. Assess pressure losses for the complete manifold; port size alone does not establish suction efficiency at the work surface.
What maintenance schedule is recommended for the VB-2000 in continuous multi-shift operations?
Request inspection and service intervals for the exact configuration and operating conditions. Confirm filter care, piston seal and valve inspection, replacement parts and any other required servicing in the operating instructions. Do not assume a universal filter interval or fixed seal life from oil-free operation alone.
Ready to Upgrade Your Industrial Vacuum System?
Send the model, target pressure, gas load, electrical supply and operating schedule for a configuration and quotation review. Request drawings and confirm availability and lead time for the proposed configuration.
